Refractoies for Coreless Furnace Melting Iron and steel
Application | Product Description | Al2O3 % | SiO2 % | MgO % | Cr2O3 % | g/cm3 | Max. Temp. oC |
Work Linig for Iron | RS DRY-RAM 101 | 0.4 | 99.2 | 2.15 | 1650 | ||
RS DRY-RAM 121S | 0.5 | 99.2 | 2.01 | 1650 | |||
RS DRY-RAM 122S | 0.5 | 99.2 | 1.9 | 1650 | |||
RS DRY-RAM 128SCR | 0.4 | 97 | 1.5 | 2.02 | 1650 | ||
RS DRY-RAM 109CR | 0.3 | 96.2 | 1 | 2.16 | 1700 | ||
Spout | RS LOW-CAST 884A | 80 | 13.1 | 2.64 | 1700 | ||
RS LOW-CAST 862A | 66.6 | 26.8 | 2.63 | 1700 | |||
RS PLASTIC 96A | 67.6 | 25.4 | 2.65 | 1650 | |||
Grout | RS COIL-GROUT 502A | 86 | 4.9 | 2.71 | 1650 | ||
RS COIL-GROUT 506A | 87.4 | 4.6 | 2.72 | 1650 | |||
RS COIL- CAST 588A | 95.8 | 0.5 | 2.86 | 1815 | |||
Structural Componens Cover | RS CAST 800A | 52.8 | 40.2 | 2.28 | 1650 | ||
RS LOW-CAST 834A | 80 | 13.1 | 2.64 | 1700 | |||
RS LOW-CAST 862A | 66.6 | 26.8 | 2.63 | 1700 | |||
RS LOW-CAST 869A | 70.2 | 27.4 | 2.65 | 1700 | |||
Maintenane | RS PLASTIC 92CR | 74.2 | 11.2 | 3.7 | 2.93 | 1750 | |
RS PLASTIC 96A | 67.6 | 25.4 | 2.65 | 1650 | |||
RS PLASTIC 98A | 67.6 | 25.4 | 2.65 | 1650 | |||
Slip&Insul ation Layer | RS MICA | 900 | |||||
RS Ceramic Cloth | 1200 |
Refractoies for Coreless Furnace Melting nonferrous
Application | Product Description | Al2O3 % | SiO2 % | MgO % | Cr2O3 % | g/cm3 | Max. Temp. oC |
Cover | RS CAST 800A | 52.8 | 40.2 | 2.28 | 1650 | ||
Work Linig for Steels | RS DRY-RAM 601A | 85.8 | 0.6 | 12.2 | 3.14 | 1815 | |
RS DRY-RAM 692A | 84.2 | 0.1 | 15.2 | 3.03 | 1810 | ||
RS DRY-RAM 693A | 88 | 0.6 | 9.7 | 3.05 | 1810 | ||
RS DRY-RAM 667CR | 80.4 | 0.2 | 14.4 | 4.8 | 3.04 | 1815 | |
RS DRY-RAM 631M | 67.6 | 0.1 | 30.5 | 3.08 | 1815 | ||
RS DRY-RAM 676M | 22.7 | 0.6 | 74.8 | 2.98 | 1815 | ||
Spout | RS LOW-CAST 884A | 80 | 13.1 | 2.64 | 1700 | ||
RS LOW-CAST 862A | 66.6 | 26.8 | 2.63 | 1700 | |||
RS PLASTIC 92CR | 74.2 | 11.2 | 3.7 | 2.93 | 1750 | ||
Grout | RS COIL-GROUT 502A | 86 | 4.9 | 2.71 | 1650 | ||
RS COIL-GROUT 506A | 87.4 | 4.6 | 2.72 | 1650 | |||
RS COIL- CAST 588A | 95.8 | 0.5 | 2.86 | 1815 | |||
Structural Componts | RS LOW-CAST 834A | 80 | 13.1 | 2.64 | 1700 | ||
RS LOW-CAST 862A | 66.6 | 26.8 | 2.63 | 1700 | |||
RS LOW-CAST 869A | 70.2 | 27.4 | 2.65 | 1700 | |||
Maintence | RS PLASTIC 92CR | 74.2 | 11.2 | 3.7 | 2.93 | 1750 | |
RS PLASTIC 96A | 67.6 | 25.4 | 2.65 | 1650 | |||
Slip&Insulation Layer | RS MICA | 900 | |||||
RS Ceramic Cloth | 1200 |
